The SWSH Series Jaw Coupling is a specially designed flexible coupling that combines the benefits of snap-wrap element design with a spacer (shaft separation) configuration. It is ideal for applications requiring easy maintenance, extended shaft distance, and minimal downtime.
The SWSH Series allows radial replacement of the elastomeric element without disturbing the hubs, while the spacer arrangement enables convenient maintenance of connected equipment such as pumps and motors without disassembly. It delivers reliable torque transmission along with excellent vibration damping and misalignment accommodation.
Allows sufficient distance between driver and driven equipment, enabling easy maintenance of connected machinery without removing the coupling hubs.
Split elastomeric element can be replaced quickly without moving shafts or hubs, reducing maintenance effort.
Ideal for critical applications where maintenance time must be minimized.
Elastomeric spider prevents direct hub interaction, reducing wear, noise, and extending service life.
Ensures continued torque transmission even in case of elastomer failure.
Accommodates angular and parallel misalignment, protecting shafts and bearings.
Absorbs dynamic loads and reduces torsional vibrations for smooth system operation.
Components:
Two Metallic Hubs
Manufactured from high-grade cast iron or steel.
Spacer Assembly (Shaft Separation Unit)
Provides extended distance between shafts, allowing maintenance without disturbing equipment alignment.
Snap Wrap Elastomeric Spider (Split Element)
Designed for radial installation and removal, available in:
- NBR (Buna-N): General-purpose applications
- Polyurethane: Higher torque and wear resistance
- Hytrel®: High temperature and high torque capability
Working Principle:
Torque is transmitted through the elastomeric snap-wrap element positioned between the jaws of the hubs via the spacer assembly. The flexible element absorbs shocks and accommodates misalignment, while the spacer ensures convenient access for maintenance without dismantling the system.
Advantages
• Enables maintenance of pumps/seals without removing hubs
• Reduces downtime in critical operations
• Easy elastomer replacement with snap-wrap design
• Suitable for installations with limited access
• Improves operational efficiency and serviceability
Typical Applications
SWSH Series Jaw Couplings are widely used in:
• Pump and motor assemblies
• Process industry equipment
• Fans and blowers
• Compressors
• Chemical and fluid handling systems
These couplings are ideal for applications requiring spacer arrangement with easy maintenance access.
Optional Variants & Customization
• Custom spacer lengths as per equipment design
• Different elastomer hardness for performance optimization
• Steel / stainless steel spacer and hub options
• Custom bore and keyway configurations as per DIN / ISO standards
• Anti-corrosion coatings for harsh environments
Combines spacer flexibility with snap-wrap maintenance convenience
Minimizes downtime and maintenance effort
Ideal for pump and motor applications requiring frequent servicing
Proven reliability in industrial environments
